#include <RV64IMACFDArch.h>

Inheritance diagram for RV64IMACFDArch:

[legend]

Collaboration diagram for RV64IMACFDArch:

[legend]

Public Member Functions
	RV64IMACFDArch (unsigned int)

virtual const std::set< std::string > &	getListenerSupportedRegisters ()

virtual ETISS_CPU *	newCPU ()
	allocate new cpu structure More...

virtual void	resetCPU (ETISS_CPU cpu, etiss::uint64 startpointer)
	reset cpu (structure) More...

virtual void	deleteCPU (ETISS_CPU *)
	delete cpu structure More...

virtual std::shared_ptr< etiss::VirtualStruct >	getVirtualStruct (ETISS_CPU *cpu)
	get the VirtualStruct of the core to mitigate register access More...

virtual unsigned	getMaximumInstructionSizeInBytes ()

virtual unsigned	getInstructionSizeInBytes ()

virtual const std::set< std::string > &	getHeaders () const
	required headers (RV64IMACFD.h) More...

virtual etiss::int32	handleException (etiss::int32 code, ETISS_CPU *cpu)
	This function will be called automatically in order to handling architecure dependent exceptions such as interrupt, system call, illegal instructions. More...

virtual void	initInstrSet (etiss::instr::ModedInstructionSet &) const
	This function is called during CPUArch initialization. More...

virtual void	initCodeBlock (etiss::CodeBlock &cb) const
	called before instructions are translated for the code block More...

virtual void	compensateEndianess (ETISS_CPU *cpu, etiss::instr::BitArray &ba) const
	Target architecture may have inconsistent endianess. More...

virtual etiss::InterruptVector *	createInterruptVector (ETISS_CPU *cpu)
	If interrupt handling is expected, vector table could be provided to support interrupt triggering. More...

virtual void	deleteInterruptVector (etiss::InterruptVector vec, ETISS_CPU cpu)
	delete an allocated interrupt vector object More...

virtual etiss::InterruptEnable *	createInterruptEnable (ETISS_CPU *cpu)

virtual void	deleteInterruptEnable (etiss::InterruptEnable en, ETISS_CPU cpu)

virtual etiss::plugin::gdb::GDBCore &	getGDBCore ()
	get the GDBcore for RV64IMACFD architecture More...

Public Member Functions inherited from etiss::CPUArch
	CPUArch (std::string archname)

virtual	~CPUArch ()

std::string	getArchName () const
	returns the name of this architecture. More...

std::string	getName () const
	returns the name of this architecture. More...

virtual unsigned	getMaximumInstructionsPerMetaInstruction ()
	maximum number of instructions in a meta instruction More...

virtual unsigned	getSuperInstructionCount ()
	fixed number of sub instructions per instruction (e.g. More...

virtual std::string	getBlockGlobalCode ()
	get c++ code snippet that is placed at the top of a translated block More...

virtual bool	unlikelyInstruction (etiss::uint8 *instr, unsigned length, bool &ismetainstruction)
	return true if the given data is unlikely to be an instruction. More...

virtual std::string	getIncludePath ()
	returns a path that will be used to look up header files More...

virtual void	finalizeInstrSet (etiss::instr::ModedInstructionSet &) const
	the default behavior of this function of a cpu arch is to add "cpu->cpuTime_ps += cpu->cpuCycleTime_ps;" if the cpu time update group is not in use More...

virtual etiss::mm::MMU *	newMMU (ETISS_CPU *cpu)
	It is an interface to instanciate a Memory Management Unit. More...

Public Member Functions inherited from etiss::CPUArchRegListenerInterface
virtual	~CPUArchRegListenerInterface ()

Public Member Functions inherited from etiss::CPUArchCPUManipulation
virtual	~CPUArchCPUManipulation ()

Public Member Functions inherited from etiss::CPUArchDefaultPlugins
virtual	~CPUArchDefaultPlugins ()

virtual etiss::Plugin *	newTimer (ETISS_CPU *cpu)
	create a simple default timer implementaion instance for this architecture. More...

virtual void	deleteTimer (etiss::Plugin *timer)
	delete timer instance More...

Public Member Functions inherited from etiss::TranslationPlugin
	TranslationPlugin ()

virtual	~TranslationPlugin ()

virtual void	finalizeCodeBlock (etiss::CodeBlock &) const
	called after all instructions have been translated for the code block More...

virtual void *	getPluginHandle ()
	called to get the handle that is available in translated code via getPoinerCode(). [default: this] More...

Public Member Functions inherited from etiss::Plugin
virtual	~Plugin ()

unsigned	getType ()

InterruptListenerPlugin *	getInterruptListenerPlugin ()

CoroutinePlugin *	getCoroutinePlugin ()

SystemWrapperPlugin *	getSystemWrapperPlugin ()

RegisterDevicePlugin *	getRegisterDevicePlugin ()

TranslationPlugin *	getTranslationPlugin ()

std::string	getPluginName () const

const std::string &	getLastAssignedCoreName ()

std::string	toString () const

Public Member Functions inherited from etiss::ToString
	ToString ()

virtual	~ToString ()

Private Attributes
std::set< std::string >	listenerSupportedRegisters_

std::set< std::string >	headers_

RV64IMACFDGDBCore	gdbcore_

unsigned int	coreno_

Additional Inherited Members
Static Public Member Functions inherited from etiss::CPUArchRegListenerInterface
static void	signalChangedRegisterValue (ETISS_CPU cpu, const char registerName)
	call this function to inform RegisterDevicePlugins about changed special register values. More...

Static Public Attributes inherited from etiss::Plugin
static const unsigned	INTERRUPTLISTENER = 1 << 0
	access to translated code More...

static const unsigned	COROUTINE = 1 << 1
	callback after execution of each translated block More...

static const unsigned	SYSTEMWRAPPER = 1 << 2
	can wrap/change ETISS_System structure at execution start More...

static const unsigned	REGISTERDEVICE
	gets noticed of changes to special registers (e.g. mmu register etc. [depends on architecture]) More...

static const unsigned	TRANSLATION
	access to translated code during translation phase or when instruction tree is built More...

Protected Member Functions inherited from etiss::CPUArch
virtual std::string	_getPluginName () const
	do not override. maps to getName(). More...

Protected Member Functions inherited from etiss::TranslationPlugin
std::string	getPointerCode () const
	returns a C code expression that allows to get or assign a pointer to the variable assigned to this translation plugin. More...

Protected Member Functions inherited from etiss::Plugin
	Plugin (unsigned type=0)

virtual void	init (ETISS_CPU cpu, ETISS_System system, CPUArch *arch)
	this function is called before the plugin is used in the cpu execution loop (etiss::CPUCore::execute). More...

virtual void	cleanup ()
	this function is called after cpu execution loop (etiss::CPUCore::execute) finished. More...

void	setCorrespondingCPUCoreName (std::string name)

virtual void	addedToCPUCore (etiss::CPUCore *core)
	called as soon a plugin has been added to its CPUCore. More...

virtual void	removedFromCPUCore (etiss::CPUCore *core)
	called as soon a plugin has been removed from its CPUCore. More...

Protected Attributes inherited from etiss::Plugin
ETISS_CPU *	plugin_cpu_
	holds a pointer to the cpu structure. will be set before init call and after cleanup call More...

ETISS_System *	plugin_system_
	holds a pointer to the system structure. More...

CPUArch *	plugin_arch_
	holds a pointer to the CPUArch instance. will be set before init call and after cleanup call More...

CPUCore *	plugin_core_
	holds a pointer to the associated CPUCore instance. More...

Detailed Description

Definition at line 28 of file RV64IMACFDArch.h.

Constructor & Destructor Documentation

◆ RV64IMACFDArch()

RV64IMACFDArch::RV64IMACFDArch ( unsigned int coreno )

Definition at line 44 of file RV64IMACFDArch.cpp.

References headers_.

Member Function Documentation

◆ compensateEndianess()

void RV64IMACFDArch::compensateEndianess	(	ETISS_CPU *	cpu,
		etiss::instr::BitArray &	ba
	)		const

virtual

Target architecture may have inconsistent endianess.

This function is called whenever a data is read from memory.

Data read from memory is buffered, and this function is called to alter sequence of buffered data so that the inconsistent endianess is compensated.

See also: RV64IMACFDArchSpecificImp.h

Target architecture may have inconsistent endianess. Data read from memory is buffered, and this function is called to alter sequence of buffered data so that the inconsistent endianess is compensated. Example for ARMv6M: void * ptr = ba.internalBuffer(); if (ba.byteCount() == 2) { ((uint32_t*)ptr) = ((uint16_t)(*((uint8_t*)ptr))) | ((uint16_t)(*(((uint8_t*)ptr)+1)) << 8); } else if (ba.byteCount() == 4) { ((uint32_t*)ptr) = ((((uint32_t)(*((uint8_t*)ptr))) | ((uint32_t)(*(((uint8_t*)ptr)+1)) << 8)) << 16) | ((uint32_t)(*(((uint8_t*)ptr)+2)) ) | ((uint32_t)(*(((uint8_t*)ptr)+3)) << 8); } else { etiss::log(etiss::FATALERROR,"Endianess cannot be handled",ba.byteCount()); }

Attention: Default endianess: little-endian

Reimplemented from etiss::CPUArch.

Definition at line 309 of file RV64IMACFDArchSpecificImp.cpp.

◆ createInterruptEnable()

etiss::InterruptEnable * RV64IMACFDArch::createInterruptEnable ( ETISS_CPU * cpu )

virtual

Reimplemented from etiss::CPUArch.

Definition at line 359 of file RV64IMACFDArchSpecificImp.cpp.

◆ createInterruptVector()

etiss::InterruptVector * RV64IMACFDArch::createInterruptVector ( ETISS_CPU * cpu )

virtual

If interrupt handling is expected, vector table could be provided to support interrupt triggering.

See also: RV64IMACFDArchSpecificImp.h

Interrupt vector table is used to inform the core whenever an edge/level triggered interrupt incoming. The content of interrupt vector could be a special register or standalone interrupt lines.

Reimplemented from etiss::CPUArch.

Definition at line 340 of file RV64IMACFDArchSpecificImp.cpp.

◆ deleteCPU()

void RV64IMACFDArch::deleteCPU ( ETISS_CPU * )

virtual

delete cpu structure

Implements etiss::CPUArch.

Definition at line 183 of file RV64IMACFDArch.cpp.

◆ deleteInterruptEnable()

void RV64IMACFDArch::deleteInterruptEnable	(	etiss::InterruptEnable *	en,
		ETISS_CPU *	cpu
	)

virtual

Reimplemented from etiss::CPUArch.

Definition at line 363 of file RV64IMACFDArchSpecificImp.cpp.

◆ deleteInterruptVector()

void RV64IMACFDArch::deleteInterruptVector	(	etiss::InterruptVector *	vec,
		ETISS_CPU *	cpu
	)

virtual

delete an allocated interrupt vector object

Reimplemented from etiss::CPUArch.

Definition at line 354 of file RV64IMACFDArchSpecificImp.cpp.

◆ getGDBCore()

etiss::plugin::gdb::GDBCore & RV64IMACFDArch::getGDBCore ( )

virtual

get the GDBcore for RV64IMACFD architecture

See also: RV64IMACFDGDBCore.h for implementation of GDBcore

Reimplemented from etiss::CPUArch.

Definition at line 221 of file RV64IMACFDArch.cpp.

References gdbcore_.

◆ getHeaders()

const std::set< std::string > & RV64IMACFDArch::getHeaders ( ) const

virtual

required headers (RV64IMACFD.h)

Implements etiss::CPUArch.

Definition at line 207 of file RV64IMACFDArch.cpp.

References headers_.

◆ getInstructionSizeInBytes()

unsigned RV64IMACFDArch::getInstructionSizeInBytes ( )

virtual

Returns: 2

Implements etiss::CPUArch.

Definition at line 199 of file RV64IMACFDArch.cpp.

◆ getListenerSupportedRegisters()

const std::set< std::string > & RV64IMACFDArch::getListenerSupportedRegisters ( )

virtual

See also: CPUArchRegListenerInterface::signalChangedRegisterValue

Implements etiss::CPUArchRegListenerInterface.

Definition at line 49 of file RV64IMACFDArch.cpp.

References listenerSupportedRegisters_.

◆ getMaximumInstructionSizeInBytes()

unsigned RV64IMACFDArch::getMaximumInstructionSizeInBytes ( )

virtual

Returns: 8 (jump instruction + instruction of delay slot)

Implements etiss::CPUArch.

Definition at line 191 of file RV64IMACFDArch.cpp.

◆ getVirtualStruct()

std::shared_ptr< etiss::VirtualStruct > RV64IMACFDArch::getVirtualStruct ( ETISS_CPU * cpu )

virtual

get the VirtualStruct of the core to mitigate register access

See also: RV64IMACFDArchSpecificImp.h

Implements etiss::CPUArchCPUManipulation.

Definition at line 316 of file RV64IMACFDArchSpecificImp.cpp.

References etiss::VirtualStruct::allocate(), and uint32_t.

Here is the call graph for this function:

◆ handleException()

etiss::int32 RV64IMACFDArch::handleException	(	etiss::int32	cause,
		ETISS_CPU *	cpu
	)

virtual

This function will be called automatically in order to handling architecure dependent exceptions such as interrupt, system call, illegal instructions.

Generated on Fri, 03 Nov 2023 13:22:23 +0100.

See also: RV64IMACFDArchSpecificImp.h

This file contains the architecture specific implementation for the RV64IMACFD core architecture.

WARNING: This file contains user-added code, be mindful when overwriting this with generated code!

This function will be called automatically in order to handling exceptions such as interrupt, system call, illegal instructions

Exception handling mechanism is implementation dependent for each cpu variant. Please add it to the following block if exception handling is demanded. Pesudo example: switch(cause){ case etiss::RETURNCODE::INTERRUPT: break;

Reimplemented from etiss::CPUArch.

Definition at line 31 of file RV64IMACFDArchSpecificImp.cpp.

References ETISS_CPU::instructionPointer, ETISS_CPU::nextPc, and RV64IMACFD_translate_exc_code().

Here is the call graph for this function:

◆ initCodeBlock()

void RV64IMACFDArch::initCodeBlock ( etiss::CodeBlock & ) const

virtual

called before instructions are translated for the code block

Reimplemented from etiss::TranslationPlugin.

Definition at line 212 of file RV64IMACFDArch.cpp.

References etiss::CodeBlock::fileglobalCode(), and etiss::CodeBlock::functionglobalCode().

Here is the call graph for this function:

◆ initInstrSet()

void RV64IMACFDArch::initInstrSet ( etiss::instr::ModedInstructionSet & mis ) const

virtual

This function is called during CPUArch initialization.

See also: RV64IMACFDArchSpecificImp.h

Function pointer length_updater_ has to be replaced if multiple length instruction execution is supported. This function enables dynamic instruction length update in order to guarantee correct binary translation Pesudo example: vis->length_updater_ = [](VariableInstructionSet & ,InstructionContext & ic, BitArray & ba) { switch(ba.byteCount()){ case 4: if ( INSTRUCTION_LENTH_NOT_EQUAL(4)){ updateInstrLength(ic, ba); ic.is_not_default_width_ = true; } break; } };

Reimplemented from etiss::TranslationPlugin.

Definition at line 60 of file RV64IMACFDArchSpecificImp.cpp.

References etiss::RegisterSet::add(), etiss::instr::Instruction::addCallback(), etiss::instr::InstructionCollection::addTo(), etiss::CodeSet::append(), etiss::instr::BitArray::byteCount(), etiss::cfg(), etiss::CodePart::code(), etiss::instr::ModedInstructionSet::compile(), etiss::instr::InstructionContext::current_address_, etiss::FATALERROR, etiss::Configuration::get(), etiss::instr::ModedInstructionSet::get(), etiss::instr::VariableInstructionSet::get(), etiss::CodePart::getAffectedRegisters(), etiss::instr::InstructionSet::getInvalid(), if(), etiss::instr::InstructionContext::instr_width_, etiss::instr::InstructionContext::instr_width_fully_evaluated_, etiss::instr::InstructionContext::is_not_default_width_, etiss::instr::VariableInstructionSet::length_updater_, etiss::log(), etiss::instr::ModedInstructionSet::print(), etiss::instr::BitArrayRange::read(), RV64IMACFDISA, and etiss::Configuration::set().
